Indoor and Outdoor Rental LED Display for Stage Events - RS Series
Product Details
| Pixelpitch: | 1.95mm(GOB)/2.6mm /2.97mm / 3.91mm | Productname: | Rental & Stage LED Display |
|---|---|---|---|
| Refreshrate: | ≥3840Hz | Controlsystem: | Nova /Colorlight Compatible |
| Lifespan: | ≥100,000 Hours | Modulesize: | 500 X 500mm/500 X1000mm |
| Application: | Rental And Stage Events | Installationmethod: | Hanging Or Stacking |
| Cabinetmaterial: | Die-cast Aluminum | Viewingangle: | Horizontal 160°, Vertical 140° |
| Brightness: | ≥5500 Cd/m² | Displaytype: | LED |
| Warranty: | 2 Years | Trade Terms: | EXW / FOB / CIF / DDP |
| Customization: | Cabinet Size, Pixel Pitch And Control System Configuration | Technical Support: | Remote Installation Guidance And After-sales Support |
| Spare Parts: | Spare Modules And Components Available According To Contract | ||
| Highlight |
stage rental led display,3840hz rental led display,stage rental outdoor led display |
||
Product Description
Indoor and Outdoor Rental LED Display for Stage Events - RS Series
RS is a modular rental LED display platform for stages, concerts, exhibitions and temporary event installations, with indoor and outdoor configurations.
A Flexible Rental Platform
The RS platform supports 500 x 500 mm and 500 x 1000 mm cabinets. Its shared 500 mm width helps rental teams plan screen ratios for different event formats. Confirm the final cabinet mix and project drawing before order confirmation.
Technical Specifications
Values are based on the supplied RS product information. Final project configuration must be confirmed against the approved specification sheet and production drawing.
| Parameter | Specification |
|---|---|
| Indoor pixel pitch | P1.95 / P2.60 / P2.97 / P3.91 |
| Outdoor pixel pitch | P3.91 |
| Cabinet size | 500 x 500 x 84.5 mm / 500 x 1000 x 84.5 mm |
| Cabinet weight | 500 x 500 mm: 8 kg |
| Cabinet material | Die-cast aluminum |
| Service access | Front and rear |
| Refresh rate | ≥3840 Hz |
| Viewing angle | 160° horizontal / 160° vertical |
| Brightness | Indoor: ≤800 / ≤1000 nits; Outdoor: ≥4500 nits |
| Ingress protection | Indoor: IP31; Outdoor: IP65 |
| Power input | AC 90-264 V, 47-63 Hz |
Applications
Concert stages, exhibitions, product presentations, corporate events and temporary indoor or outdoor video walls.
Frequently Asked Questions
How should I select the RS configuration?
Select the pixel pitch, indoor or outdoor configuration, cabinet format and installation method according to viewing distance, venue conditions and the approved project design.
Can CHEER OPTO support project planning?
Share the required screen size, event type, destination country and installation method. The CHEER OPTO team can recommend an appropriate configuration.
Request a Rental LED Display Proposal
Contact CHEER OPTO with your project requirements for configuration, control system and service support.
