Product Details:
|
| Application: | Indoor Commercial Advertising | Color: | Black |
|---|---|---|---|
| Panel Size: | 640*480mm | Pixel Pitch: | P1.2 P1.5 P1.6 P1.8 P2 P2.5 P3 P4 |
| Installation: | Floor Standing Wall Mounting Hanging | Brightness: | 500-800 Nits |
| Warranty: | 2 Years | Module Size: | 320x160mm |
| Refresh Rate: | 1920-3840Hz | Cabinet Material: | Die-casting Aluminum |
| Viewing Angle: | 160/160 Degree | LED Type: | SMD 1010 SMD 1212 SMD 1515 SMD 2020 |
| Input Voltage: | AC 100-240V 50/60Hz | Lifespan: | 100 000 Hours |
| High Light: | SMD2020 High Brightness Led Display,AC240V High Brightness Led Display,500nits Indoor Led Display Screen |
||
* Multiple installation, Hanging and stacking, wall mounting
Specification
|
Mini169
|
P1.81
|
P1.56
|
P1.667
|
P2.2
|
P2.5
|
|
LED SMD Mode
|
SMD1.81
|
SMD1212
|
SMD1212
|
SMD1212
|
SND1515
|
|
Pixel Pitch
|
1.81mm
|
1.56mm
|
1.667mm
|
2.2mm
|
2.5mm
|
|
Pixel Density (dots/㎡)
|
302500
|
409600
|
360000
|
202500
|
160000
|
|
Pixel Structure
|
1R1G1B
|
||||
|
Module Resolution
|
176X99dots
|
204X114dots
|
192X108dots
|
144X81dots
|
128X72dots
|
|
Brightness
|
450~500CD/㎡
|
||||
|
Driving Method
|
99Scan
|
57Scan
|
108Scan
|
81Scan
|
36Scan
|
|
Horizontal View Angle
|
≥178°
|
||||
|
Vertical View Angle
|
≥178°
|
||||
|
Optimum View Distance
|
1m~32m
|
||||
|
Working Temperature
|
-20℃~+40℃
|
||||
|
Working Humidity
|
10%~90% RH
|
||||
|
Storage Humidity
|
30%~60% RH
|
||||
|
Module Size(W*H*D)
|
320mm*180mm*10mm
|
||||
|
Module Weight
|
650.0±10g
|
||||
|
Module Deformation Height
|
≤0.1mm
|
||||
|
Structure
|
Aluminum Frame Housing+ Rear-cover Seal-up
|
||||
|
Cabinet Deformation Precision
|
≤0.1mm
|
||||
|
Maintainance Method
|
Die-casting Aluminum Full-Front Maintainance
|
||||
|
Input Voltage(DC)
|
4.2~5.5V
|
||||
|
Max. Current
|
5A
|
||||
|
Max. Power/㎡
|
450W
|
||||
|
Pixel Out of Control Rate
|
﹤0.0001
|
||||
Product Discription
Application
Q1. What about LED Display MOQ?
Contact Person: Jack
