Flexible Transparent Film LED Display for Curved Glass Surfaces
Product Details
| Max Power Consumption: | 800w/m2 | Weight: | 1.5kg/Plece(6kg/m2) |
|---|---|---|---|
| Viewing Angle: | 140%/120° | Led Lamp: | SMD1717 |
| Module Resolution: | 256x64 Dots/384x64 Dots | Pixel Density: | 65536 Dots/sq.m |
| Transparency: | 92% | Brightness: | 3000/1500CD/m2 |
| Warranty: | 2 Years | Trade Terms: | EXW / FOB / CIF / DDP |
| Customization: | Cabinet Size, Pixel Pitch And Control System Configuration | Technical Support: | Remote Installation Guidance And After-sales Support |
| Spare Parts: | Spare Modules And Components Available According To Contract | ||
| Highlight |
800w/M2 Transparent Film LED Display,92% Transparency Transparent Film LED Display,Commercial led transparent film screen |
||
Product Description
CHEER OPTO · TRANSPARENT FILM LED DISPLAY
Transparent Film LED Display for Retail Storefront Windows
A transparent film LED display for retail storefront windows, designed to add digital content while preserving glass visibility and natural light.
Designed for glass media projects
Storefront-Friendly Transparency
90% - 95% transparency by model helps maintain daylight and views through the retail window.
Self-Adhesive Glass Installation
The thin-film structure supports direct attachment to suitable glass surfaces without a heavy rear frame.
Daytime Retail Media
Specified brightness options support content visibility across different interior and storefront lighting conditions.
Applications
Retail Storefront Windows
Promotions, launches and brand content visible from both outside and within the store.
Shopping Mall Entrances
Transparent digital media for glass entrances and commercial display zones.
Automotive and Showroom Glass
Product and campaign messaging for glass-fronted display environments.
Technical Specifications
| Parameter | TF Series Specification |
|---|---|
| Models | TF5 / TF6.25 / TF8 / TF10 / TF15 / TF20 |
| Module Size | 320 x 1000 / 400 x 1000 / 390 x 990 / 1000 x 400 mm, by model |
| LED Specification | 1313 / 2121 Mini LED |
| Pixel Density | 4000 / 4356 / 10000 / 15625 / 25600 dots/m2, by model |
| Brightness | 2000 - 4000 cd/m2 |
| Transparency | 90% / 92% / 94% / 95%, by model |
| Viewing Angle | 160 degrees horizontal / 160 degrees vertical |
| Maximum Power Consumption | 600 W/m2 |
| Average Power Consumption | 200 W/m2 |
| Weight | 2 kg/m2 |
| Thickness | 2 mm |
| Refresh Rate | 3840 Hz |
| Gray Scale | 16 bit |
| Rated Lifespan | 100,000 hours |
| Core Structure | Self-adhesive, frameless and flexible film structure |
FAQ
Can TF be installed on glass without a steel frame?
The supplied product material describes a self-adhesive film structure intended for direct glass attachment. Confirm glass condition, wiring and final installation method for each project.
Product Highlights
Flexible transparent film LED display for curved glass surfaces, with 90%-95% transparency, 2 mm film thickness and self-adhesive installation.
