Product Details:
|
| Material: | Die-Aluminum | Brightness: | 800-1000cd/4000-6000cd |
|---|---|---|---|
| Refresh Rate: | 1920-3840hz | Weight: | 25kg/sqm |
| Cabinet Size: | 500*500mm/500*1000mm | Viewing Angle: | 160/160 |
| Color Temperature: | 3200-9300k | Grey Scale: | 16 Bit |
| Maintenance Way: | Front And Rear | Voltage: | 100-240V |
| High Light: | ROHS Led Screens For Events,6000cd Led Screens For Events,ROHS 4k led display |
||
High Brightness 6000cd Indoor Outdoor 2K 4K Led Rental Display Led Screens For Events
Advantage:
Specification
| Model | R-2.604 | R- 2.97 | R-3.91 | R-3.91 | R-4.81 |
| Pixel Pitch (mm) | 2.604 | 2.97 | 3.91 | 3.91 | 4.8 |
| Application | Indoor Rental | Outdoor Rental | |||
| Pixel Density (dot/m²) | 147456 | 112896 | 65536 | 65536 | 43264 |
| LED Configuration | SMD2020 | SMD2020 | SMD2020 | SMD1921 | SMD2727 |
| Brightness (CD/m²) | ≥800nit | ≥1000nit | ≥1000nit | ≥5000nit | ≥5000nit |
| Module Size (mm*mm) | 250*250mm | ||||
| Module Resolution (dot*dot) | 96*96 | 84*84 | 64*64 | 64*64 | 52*52 |
| Cabinet Size (W*H*D)/(mm) | 500*500*80 | ||||
| Cabinet Resolution (dot*dot) | 192*192 | 168*168 | 128*128 | 128*128 | 104*104 |
| Material | Die-casting Aluminum | ||||
| Angle Lock Degree | ±5°,±10° | ||||
| Cabinet Weight (±0.25kg) | 7.0kg/cbn | 7.0kg/cbn | 7.0kg/cbn | 7.5kg/cbn | 7.5kg/cbn |
| Viewing Angle | Horizontal:140° Vertical:140° | ||||
| Refresh Rate (Hz) | ≥1920hz / ≥3840hz | ||||
| Viewing Distance (m) | >2.6m | >2.84m | >3.91 | >4.81 | |
| Gray Scale (bit) | 14bit | ||||
| Max/Avg. Consumption (W/m²) | 480W/180W | 480W/180W | 500W/200W | 560W/220W | 600W/250W |
| AC Input (V) | 100～240V | 100～240V | 100～240V | 100～240V | 100～240V |
| AC Frequency (Hz) | 50～60Hz | 50～60Hz | 50～60Hz | 50～60Hz | 50～60Hz |
| Waterproof Level | IP43 | IP43 | IP43 | IP65 | IP65 |
| Maintenance | 100% Front & Rear Service | ||||
| Control system | Nova/Linsn/Colorlight.. | ||||
Applications:
Widely used in billboards, highways, railway tunnels, bridges, squares, stadiums,
tparking lots, building walls, hotel, meeting room, offices , hospital , schools ,
flactories , commercial lighting , shopping malls, supermarkets,concerts,
TV show and so on
FAQ:
Q1. What about LED Display MOQ?
Contact Person: Jack
