Product Details:
|
| Material: | Die-Casting Aluminum | Weight: | 7.5 Kg |
|---|---|---|---|
| Refresh Rate: | 3840Hz | Gray Level: | 16 Bit |
| Control System: | Novastar Colorlight | Contrast Ratio: | 8000 :1 |
| Curve Degree: | +15° -15° | Color: | 65 - 281 Trillion |
| High Light: | P3.91 curved led display,SMD curved led display,P3.91 smd led display |
||
HD Full Color SMD Curved Led Display Panel Rental P2.97 P3.91 P4.81
|
Advantages
|
|
1. Classical design and natural technic,reliable quality and great performance.
2. Seamless connecting tech.,screen flatness error <0.1mm.
3. Patented mask,eliminating the dark spots,improving consistency and viewing angle. Vertical 160°,horizontal 160°
4. High contrast,ideal gray scale,presenting the most real pictures. 3840hz refresh rate and 16 bit gray scale
5. Supporting brightness and color correcting of the whole screen.
 Easy Maintenance: module size---250x500mm * Modules can be taken out without opening the back door. * Power suppliers are fixed without screws.
|
Right angle mixed splicing with curved angle: Straight and curved cabinets can be connected together seamlessly by lock. Support inner and outer arc Angle: 0°/ 5°/ 10° / 15°Detachable design positioning pin
convenient to take out the whole cabinet from the middle when the big screen set up
Special structural hanging bar design that helps you to install the screen on ceiling easily
|
Specifications
|
|
|
|
|
|
|||||
|
Model
|
A-P2.84
|
A-3.91
|
A-3.91
|
A-4.81
|
A-5.95
|
|||||
|
Pixel Pitch (mm)
|
2.84
|
3.91
|
3.91
|
4.8
|
5.95
|
|||||
|
Application
|
Indoor Rental
|
|
Outdoor Rental
|
|
|
|||||
|
Pixel Density (dot/m²)
|
147456
|
112896
|
112896
|
65536
|
43264
|
|||||
|
LED Configuration
|
SMD2020
|
SMD2020
|
SMD1921
|
SMD2727
|
SMD2727
|
|||||
|
Brightness (CD/m²)
|
≥1000nit
|
≥1000nit
|
≥5000nit
|
≥5000nit
|
≥5500nit
|
|||||
|
Module Size (mm*mm)
|
250*250mm
|
|
|
|
|
|||||
|
Module Resolution (dot*dot)
|
96*96
|
64*64
|
64*64
|
52*52
|
42*42
|
|||||
|
Cabinet Size (W*H*D)/(mm)
|
500*500*80
|
|
|
|
|
|||||
|
Cabinet Resolution (dot*dot)
|
192*192
|
128*128
|
128*128
|
104*104
|
84*84
|
|||||
|
Material
|
Die-casting Aluminum
|
|
|
|
|
|||||
|
Angle Lock Degree
|
±5°,±10°
|
|
|
|
|
|||||
|
Cabinet Weight (±0.25kg)
|
7.0kg/cbn
|
7.0kg/cbn
|
7.5kg/cbn
|
7.5kg/cbn
|
7.5kg/cbn
|
|||||
|
Viewing Angle
|
Horizontal:140° Vertical:140°
|
|
|
|
|
|||||
|
Refresh Rate (Hz)
|
≥1920hz / ≥3840hz
|
|
|
|
|
|||||
|
Viewing Distance (m)
|
>2.84m
|
>3.91
|
|
>4.81
|
>5.95
|
|||||
|
Gray Scale (bit)
|
14bit
|
|
|
|
|
|||||
|
Max/Avg. Consumption (W/m²)
|
480W/180W
|
500W/200W
|
560W/220W
|
600W/250W
|
650W/280W
|
|||||
|
AC Input (V)
|
100～240V
|
100～240V
|
100～240V
|
100～240V
|
100～240V
|
|||||
|
AC Frequency (Hz)
|
50～60Hz
|
50～60Hz
|
50～60Hz
|
50～60Hz
|
50～60Hz
|
|||||
|
Waterproof Level
|
IP43
|
IP43
|
IP65
|
IP65
|
IP65
|
|||||
|
Maintenance
|
100% Front & Rear Service
|
|
|
|
|
|||||
|
Control system
|
Nova/Linsn/Colorlight..
|
|
|
|
|
|||||
Applications:
Widely used in billboards, highways, railway tunnels, bridges, squares, stadiums,
tparking lots, building walls, hotel, meeting room, offices , hospital , schools ,
flactories , commercial lighting , shopping malls, supermarkets,concerts,TV show and so on
