Holographic Transparent LED Display for Retail Storefronts and Showrooms
Product Details
| Power Consumption: | 50 Watts | Contrast Ratio: | 10000:1 |
|---|---|---|---|
| Color: | Full Color | Color Temperature: | 6500-9000 |
| Supported Formats: | MP4, AVI, MOV, WMV, Etc. | Led Technology: | High Brightness LEDs |
| Sunlight Readable: | Yes | Weight: | 6 Kg |
| Content Format: | Video/Image/Text | Installation Method: | Wall-mounted |
| Keyword: | LED Display Screen Panels | Connectivity: | Wired/Wireless |
| Display Mode: | 3D | Power Supply: | AC 100-240V |
| Compatibility: | Compatible With Various File Formats | Warranty: | 2 Years |
| Trade Terms: | EXW / FOB / CIF / DDP | Customization: | Cabinet Size, Pixel Pitch And Control System Configuration |
| Technical Support: | Remote Installation Guidance And After-sales Support | Spare Parts: | Spare Modules And Components Available According To Contract |
| Highlight |
Invisible Holographic LED Display,Wall Mounted Holographic LED Display,50 Watts led holographic display |
||
Product Description
Create dynamic digital visual communication on glass-facing retail spaces while preserving the openness of the storefront. The HT series provides multiple pixel-pitch and transparency options so the display can be matched to viewing distance, ambient conditions and project requirements.
- High-transparency presentation
Transparency options from 70% to 98% help retain daylight, merchandise visibility and architectural openness.
- Slim, lightweight display body
The specified module weight is 2 kg/m² with a thickness of no more than 2 mm, supporting discreet integration on suitable glass-facing surfaces.
- Clear visual performance for close viewing
Choose from PH2.5 to PH20 to balance content detail, viewing distance and transparency for the installation.
- Retail storefront windows and shopping-mall glass facades
- Brand showrooms and product-launch displays
- Glass partitions, atriums and reception areas
Select the configuration according to the project’s viewing distance, transparency requirement and installation conditions. Values below are taken from the HT series specification document.
| Specification | PH2.5 | PH3.5 | PH3.91 | PH5 | PH6.25 | PH7.8 | PH10 | PH15.625 | PH20 |
|---|---|---|---|---|---|---|---|---|---|
| Pixel Pitch | 2.5 mm | 3.5 mm | 3.91 mm | 5 mm | 6.25 mm | 7.8 mm | 10 mm | 15.625 mm | 20 mm |
| Transparency | 70% | 80% | 85% | 88% | 90% | 95% | 95% | 95% | 98% |
| Pixel Density (dots/m²) | 160,000 | 81,225 | 65,536 | 40,000 | 25,600 | 15,625 | 10,000 | 4,096 | 2,500 |
| Module Size | 1500 × 160 mm | 1500 × 224 mm | 1500 × 250 mm | 1500 × 250 mm | 1500 × 250 mm | 1500 × 250 mm | 1500 × 250 mm | 1500 × 250 mm | 1500 × 240 mm |
| Recommended Viewing Distance | 3–100 m | 5–100 m | 6–100 m | 8–100 m | 10–100 m | 12–100 m | 15–120 m | 20–120 m | 25–120 m |
| Average Power Consumption | ≤300 W/m² | ≤240 W/m² | ≤240 W/m² | ≤240 W/m² | ≤240 W/m² | ≤240 W/m² | ≤240 W/m² | ≤200 W/m² | ≤120 W/m² |
| Maximum Power Consumption | ≤800 W/m² | ≤800 W/m² | ≤800 W/m² | ≤800 W/m² | ≤800 W/m² | ≤800 W/m² | ≤800 W/m² | ≤600 W/m² | ≤400 W/m² |
| LED Configuration | 1R1G1B | ||||||||
| Module Weight | 2 kg/m² | ||||||||
| Viewing Angle | 160° | ||||||||
| Thickness | ≤2 mm | ||||||||
| Supply Voltage | 5 V | ||||||||
| Refresh Rate | ≥3840 Hz | ||||||||
| White Balance Brightness | ≤5000 cd/m² | ||||||||
| Operating Temperature | -20°C to 55°C | ||||||||
| Drive Mode | Static drive | ||||||||
| MTBF | ≥6500 hours | ||||||||
| Service Life | 100,000 hours | ||||||||
| Protection Rating | IP43 | ||||||||
Product Highlights
Holographic transparent LED display for retail storefronts, showroom windows and glass-facing brand spaces. Choose HT configurations from PH2.5 to PH20.
